Forklift Pinions

Pinion for Forklift - The main pivot, referred to as the king pin, is found in the steering device of a forklift. The very first design was a steel pin wherein the movable steerable wheel was attached to the suspension. Able to freely revolve on a single axis, it restricted the degrees of freedom of movement of the rest of the front suspension. During the 1950s, the time its bearings were replaced by ball joints, more comprehensive suspension designs became accessible to designers. King pin suspensions are nonetheless featured on various heavy trucks because they can lift a lot heavier load.

The newer designs of the king pin no longer restrict to moving like a pin. Now, the term may not even refer to a real pin but the axis wherein the steered wheels pivot.

The KPI or likewise known as kingpin inclination can also be referred to as the steering axis inclination or SAI. These terms describe the kingpin when it is set at an angle relative to the true vertical line as looked at from the front or back of the forklift. This has a major effect on the steering, making it likely to go back to the centre or straight ahead position. The centre arrangement is where the wheel is at its uppermost position relative to the suspended body of the lift truck. The motor vehicles weight tends to turn the king pin to this position.

Another impact of the kingpin inclination is to fix the scrub radius of the steered wheel. The scrub radius is the offset amid the projected axis of the steering down through the kingpin and the tire's contact point with the road surface. If these items coincide, the scrub radius is defined as zero. Though a zero scrub radius is possible without an inclined king pin, it requires a deeply dished wheel so as to maintain that the king pin is at the centerline of the wheel. It is more practical to incline the king pin and use a less dished wheel. This also offers the self-centering effect.
